美松一二维码影像式扫描枪 1.快速准确识别一维码 ,二维码 纸质和手机码 2.无需插件,闪电开票 对接多种主流开票软件 3.即插即用,免驱动更简单 4.进口按键,寿命更长 5.支持USB,USB虚拟串口,232串口
美松一二维码影像式扫描枪MS-6100扫描采用国际解码算法,即插即用,免驱动更简单,对各种一维,二维条码,纸质和电子屏码均以快速精准解读；尤其对残缺码,污损码和变形码有非常强的纠错能力,兼容WINDOWS ,Linux,安卓等主流操作系统,广泛用于零售餐饮仓库快递行业,手机屏幕收银行业.
关联产品 :MS-7710 MS-20E MS-20 MS-28 MS-2102 MS-2104 MS-7200 MS-6400 MS-4200N MS-3200V
MS-7160N MS-7120N MS-6601 MS-7180
相关推荐 :微型打印机 针式打印机 热转印打印机 智能一体机 票据打印机 嵌入式热敏打印模块 无版烫金机 微型打印机 关于美松
物理特性/Physical Characteristics |
||
尺寸 Dimensions: |
160mm x 64mm x 97mm |
|
重量 Weight: |
140.5g |
|
电压 Voltage: |
5±5%V |
|
开机电流 Starting Current: |
160mA |
|
待机电流 Stand-by Current: |
120mA |
|
工作电流 Work Current: |
330mA |
|
性能指标/Performance Characteristics |
||
传感器像素 Image (Pixels): |
640 pixels (H)x480 pixels (V) |
|
光源 Light Source: |
(Aimer) Red color LED; (Illumination) White color LED |
|
旋转/倾斜/偏转 Roll / Pitch / Yaw: |
360°(Roll), ±65°(Skew) , ±65°(Pitch) |
|
打印对比度Print Contrast: |
20% minimum reflective difference |
|
接口支持 Interfaces Supported: |
USB |
|
运动容差Motion Tolerances: |
>0.4m/s |
|
解码能力/Symbology Decode Capability |
||
一维条码/1-D: |
Codabar,Code 39,Code 32 Pharmaceutical (PARAF),Interleaved 2 of 5,NEC 2 of 5,Code 93,Straight 2 of 5 Industial,Straight 2 of 5 IATA，Matrix 2 of 5，Code 11,Code 128,GS1-128,UPC-A,UPC-E ,EAN/JAN-8,EAN/JAN-13,MSI,GS1 DataBar Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,China Post(Hong Kong 2 of 5),Korea Post |
|
二维条码/2-D: |
Codeblock A,Codeblock F,PDF417,Micro PDF417,GS1 Composite Codes, QR Code,Data Matrix,MaxiCode,Aztec,HANXIN |
|
默认开启码制: |
Codabar,Code39,Interleaved2of5,NEC2of5,Code93,Code128,GS1-128,UPC-A,UPC-E 0,EAN/JAN-13,EAN/JAN-8,GS1-DataBar,PDF417,QR,DM,Aztec |
|
条码精度Minimum Resolution |
≥4mil |
|
用户环境参数/User Environment |
||
工作温度 Operating Temperature: |
-20°C to 60°C |
|
存储温度 Storage Temperature: |
-30°C to 70°C |
|
湿度 Humidity: |
5% to 95% relative hum idity,non-condensing |
|
抗震性 Shock Specifications: |
Designed to withstand 1.2m(5’) drops |
|
环境光免疫 Ambient Light Immunity: |
0-100,000 Lux. |
|
解码范围/Decode Ranges |
||
5 mil (Code 39) |
20mm-120mm |
|
13 mil (Code 39) |
30mm-270mm |
|
Performance may be impacted by bar code quality and environmental conditions |
||
|
||
